Input specifications
- Voltage max (V)
- 415
- Frequency (Hz)
- 50
- Phases
- 3
DC
E Fill Electric
X5 Series EV Charger
DC CCS2 180 kW Output Stand Alone
Easy Installation Multiple Fault Protection On Board Earthing Protection IP 55 High Portability Fast Charger Dual Connector Safe And Reliable
Technical Specifications
Output characteristics
- Frequency (Hz)
- 50
- Rating (kW)
- 180
Recommended environment
- Ambient min (°C)
- -20
- Ambient max (°C)
- 75
- Storage min (°C)
- 0
- Storage max (°C)
- 55
- Humidity min (%)
- 5
- Humidity max (%)
- 95
- Altitude max (m)
- 2000
Protection
- IP rating
- 54
- Cooling type
- Forced Air Cooling Fan
- Overheating protection
- Yes
- Earth leakage protection
- Yes
Communication
- GSM
- Yes
- LAN
- No
- Wi-Fi
- Yes
- Ethernet
- Yes
- Supported protocols
- OCPP_1_6
Dimensions
- Height (mm)
- 1746
- Width (mm)
- 960
- Length (mm)
- 583
- Weight (kg)
- 380
